The Luxvision ABG-3000 Automatic Lens Edger and Beveler is a multifunctional unit that is both durable and easy to operate. The unit accepts polycarbonate, plastic, and glass, and features an imported diamond wheel. You can now prepare lenses for virtually any prescription or frame style, including polycarbonate materials. Operators will benefit from the flexibility to create center, front, or rear curve grooving in approximately 60 seconds.
Bevels and grooves lenses in a single durable, long-lasting unit.
Accepts polycarbonate, plastic, and glass to accommodate any prescription.
Creates central, front, or posterior curved grooving according to the frame style.
Completes lens grooving in approximately 60 seconds.
ABG-3000 Features
▪ Versatile combined unit
▪ More options
▪ Fast and easy to use
▪ Excellent precision
▪ Quality construction
Combined Unit
With the Luxvision ABG-3000, operators will enjoy the flexibility of being able to groove and bevel lenses without the need to switch machines or invest in two separate units.
More Options
Many of today’s customers require plastic and polycarbonate designs. With the ABG-3000, creating these lenses is no problem at all. You can even select between central, front, or rear curved grooving for greater flexibility.
Easy to use
El ABG-3000 is easy to use, regardless of experience level. Technicians can quickly learn to correctly and efficiently operate this automated unit. Best of all, it is fast. It can groove lenses in approximately 60 seconds.
Excellent Precision
Lens grooving and beveling is a critical part of lens processing. The ABG-3000 offers unparalleled precision, while providing operators with the level of control they require and value.
Quality Construction
The Luxvision brand is one you can trust. From the outer casing to the diamond wheel, every component of the ABG-3000 features high-quality craftsmanship and has been carefully built and designed.
mineral / plastic lenses
0 - 0.03in / 0.7mm
0.02in / 0.6mm
0.06 - 0.43in (1.5 - 11.0mm)
1.10 - 2.76in (28 - 70mm)
approximately 60 seconds
6.7(W) x 8.3(L) x 6(H) in (170(W) x 210(L) x 150(H) mm)
5.94lb / 2.7kg
100 - 120V / 60Hz AC 200 - 240V / 59Hz AC 50W
